Dimmable LED Driver-100W

100W, 12V CV Dimmable LED Driver
100W, 12V CV Dimmable LED Driver
100W, 12V CV Dimmable LED Driver

Dimmable LED Driver-100W

(2 customer reviews)
MSRP: $

$123.75

Dimmable 100 watt 12V DC Constant Voltage driver. Compatible with Triac dimming switches. Can be used in a dry or wet location.

Product Options:

In stock

PDF
SKU: DVR902 Categories: , ,

Dimmable LED Driver-100W

This massive capacity 100W, 12V DC dimmable LED driver is useful for higher consumption lights or large systems. It is a perfect pairing with our unique 2216 dot-less under cabinet kitchen lights. We recommend 2216 when you are looking for the maximum amount of light.

Also, unlike many drivers, it is compatible with both forward and reverse phase dimming switches. We recommend a Lutron DVCL153 dimmer for use with the driver.

The driver is pre-installed in the junction box, which is IP67 rated, making it suitable for wet locations. These drivers are cETL certified for use in Canada. The metal electrical box has separate compartments for line and low-voltage wires meeting all Canadian electrical codes.

If you are unsure this is the right choice for your project, call us at 1-800-677-2698 to help size your driver correctly work with your lighting system.

Triac Dimmable
Overload Protection
Open Circuit Protection
Short Circuit Protection
Over Temperature Protection
Limited 5-year Warranty
Flicker-free Dimming

Driver Size: 230 x 70 x 46 mm (9.05 x 2.76 x 1.81 inches)
Junction Box Size: 360 x 75 x 55 mm (14.17 x 2.95 x 2.61 inches)
Input: 100-130V AC 50/60Hz
Input Current: 1.6A
Output: 12V DC, Constant Voltage
Rated Power: one wire supplying a total of 100W
Output Current: 8.3A max
Minimum Load: 5 watts
Maximum Load: 100 watts
Short Circuit, Open Circuit, Temperature, and Overload protection
Wet Rated (indoor/outdoor rated)
Temperature: -40C – +60C
Ambient Temperature ta: Max. 40 C
Certification: Class II AC Input (2-wire connection, requires no ground)- Complies with FCC Part 15B

2 reviews for Dimmable LED Driver-100W

  1. Brent Redberger (verified owner)

    Works perfect with Lutron DVCL-153P-IV dimmer.
    Using for kitchen under cabinet LED strip lighting.
    Startup is fast and dimming is stable with no flicker.

  2. Jonathan Boudreau (verified owner)
