Hippo Lead Connectors

8mm Single Colour Hippo Lead Connector
8mm Single Colour Hippo Lead Connector
FIX1 Hippo RGB Lead Connector
Hippo RGB Lead Connector
Hippo RGBW Lead Connector Indoor and Outdoor
Hippo RGBW Lead Connector

Hippo Lead Connectors

$1.50$4.60

Use the solderless Hippo Lead Connector to add a lead to your cut pieces of flex strips. Options Available in 8mm 2-pin Single Colour, 4-pin RGB and 5-pin RGBW.

Quick and simple to install. Suitable for indoor and outdoor applications.

Please note that the wire is not included, which allows you to install any length of wire to the connector. View our 10ft 2-conductor, 4-conductor and 5-conductor wire.

Product Options:

Hippo Lead Connectors

Need a wire lead on the end of your LED Flex strip? Use the solderless Hippo Lead Connectors to add a lead to your cut pieces of flex strips. Available for 8mm Single Colour, RGB, and RGBW flex strips. Perfect for long-distance installations since you provide the length of low voltage wire.

Quick and easy to install. First, peel a little bit of the sticker paper off of the strip. Push the strip into the groove and place it on the metal pins. Make sure that the pins line up with the copper contacts on the flex strip. Once all the points are aligned, clamp the plastic tab down. Repeat the same steps for the other end with the wires, checking that the polarity is consistent and you’re done! The Hippo Connectors create secure connections by piercing through the flex strip’s copper contacts.

Suitable for use with indoor and outdoor Flex strips. The Hippo Lead Connector is compatible with most Single Colour, RGB, and RGBW low voltage flex strips.

Please note that the wire is sold separately. View our 10ft 2-conductor, 4-conductor and 5-conductor wire.

Browse our full selection of Hippo Connectors.

Canadian support is available both before and after the sale. We will assist you in layout and design as well as provide tech support for any product you purchase from us. Call us Toll Free at 800-677-2698 or email info@ledlightscanada.com. We are here to help.

How to install the strip:
Hippo Strip Instructions

How to install the wires:

Type: Lead – strip to wire, wire not included
Strip Width: 8mm Single Colour, 10mm RGB, 12mm RGBWW
Strip Type: Single Colour, RGB, and RGBW
Max. Voltage: 24V DC
Max. Current: 3.5A
Size: Single Colour – 19.6 x 12.6 x 7.7m, RGB – 24.3 x 14.6 x 7.7mm, RGBW – 24.3 x 17 x 7.7mm
Material: Polycarbonate, Copper
Wire: no wire, fits 22-20AWG
